LG (14HQ901G) Digital X-ray Detector with Oxide TFT (14x17-inch)

LG (14HQ901G) Digital X-ray Detector (14"x17" ) (36 cm x43 cm) with Oxide TFT

LG (14HQ901G) Digital X-ray Detector (14"x17" ) (36 cm x43 cm) with Oxide TFT

₹1,006,880.00

(Incl. GST)

21% OFF

MRP : ₹1,290,000.00
Brand :
LG
Out of stock
Features
  • Medilife - 14x17 -inch Digital X-Ray Detector with Oxide TT
  • Higher Accuracy with up to 57.9% Lower exposure
  • High-density CsI AED Detector with oxide TT
  • Improved Portability for Maximum Convenience
  • More Convenient and a Faster Diagnosis Processing

LG (14HQ901G) Digital X-ray Detector (14"x17" ) (36 cm x43 cm) with Oxide TFT

SPECIFICATIONS

  • Higher Accuracy with up to 57.9% Lower Exposure:
  • High-sensitivity CsI AED Detector with Oxide TFT: The LG 14HQ901G features an oxide-based thin-film transistor (TFT) with electron transfer speeds almost 100 times faster than a conventional TFT. By increasing the Csl thickness of the 14HQ901G from 300um to 500um, LG has also managed to improve the Detective Quantum Efficiency (DQE) of the new oxide-based TFT by 28% to only 1 Ip/mm, compared to standard a-Si detectors. The combination of enhancements to image processing in the latest version of
    LG’s AWS (Acquisition Work Station Software) and DXD improvements allows the new LG 14HQ901G to acquire accurate X-Ray images while reducing radiation exposure by up to 57.9%
  • Improved Portability for Maximum Convenience:
  • Improved Design (Handle | 4-side chamfer) | Long Battery Life | Hot Swap: LG Digital X-ray Detectors have been redesigned with a handle added to the back of the device. Combined with sculpted handgrips and chamfers, this makes the detector easy to carry and position for increased portability and convenience. The device has up to 8 hours of battery life, plus Hot Swap built-in and removable batteries, that allow the device to maintain power for up to 1 minute when the battery is removed to ensure seamless use.
  • IP68: Waterproofing & Dustproofing | Load Weight :LG Digital X-ray Detectors are protected against external contaminants with an IP68 dustproof and waterproof rating. Level 6 dust proofing means that the device is fully protected against the ingress of dust, while level 8 water resistance means that the device is watertight even when immersed under pressure for long periods. This reduces the risk of malfunction even when used in external environments or moving the device from station to station. Additionally, the 14HQ901G has a load weight of 400kg and a point weight of 200 kg for maximum strength and reliability.
  • More Convenient and a Faster Diagnosis Processing:
  • SW Grid: LG SW Grid estimates and corrects scatter radiation, eliminating the need for a physical grid when using the device. Although no physical grid is used, SW Grid's image quality is comparable to that of images processed using a grid.



Dimension / Weight 384 mm x 460 mm x 15.6 mm;3.0 kg
Intended Use General Radiography
TFT Type Oxide
Scintillator CsI
Pixel Pitch 140 ㎛
Number of Pixels 2560 x 3072 pixels
TFT Active Area 358.40 x 430.08 mm
MTF @ 0.5lp/mm (Typ.) 84%
DQE @ 0.1lp/mm (Typ.)
78%
A/D Conversion
16 bit
Data Output
16 bit
Type
Wired / Wireless
WLAN IEEE802.11a/b/g/n/ac, 2.4GHz/5GHz
Auto Exposure Detection
Yes
Cycle Time
4.5 sec (Wired) / 5 sec (Wireless)
Full Image Transfer (Typ.)
1.5 sec (Wired) / 2 sec (Wireless)
Maximum Load Weight
Full (Uniform Load): 400 kg (881.8 lbs)
Local (Point Load): 200 kg (440.9 lbs)
Watertightness
IP68
Sensor Protection Plate
Carbon Fiber Plate
Operation Time
320 shots / 8.0 hrs (Typ.)
(Condition: Cycle Time 90 sec)
Battery Charging Time 3 hrs (Typ.)
Hot Swap Yes (1 Min)
Cable Power Cord, Main Cable 7 m (LAN Cable, Sync Cable Option)
Accessories Battery Charger
Other
2 x Battery Packs
  Control Box
