Infusion Rate : 1 mL/h to 1200 mL/h
Flow Accuracy : ±5% (accuracy of qualified infusion set after calibration)
Priming / Bolus Dosage Rate : 1000 mL/h
Infusion Volume : 1 mLto 9999 mL
Accumulative Volume : 0 mL to 9999 mL (0.1 mL increment)
History Records : Up to 1500 records
Occlusion Alarm Threshold
High : 107.1 kPa to 174.8 kPa
Middle : 54.1 kPa to 110.2 kPa
Low : 2 kPa to 45.1 kPa
Ultrasonic Bubble Detector Sensitivity : ≥25 μL
KVO Rate : 0 mL/h to 5 mL/h (adjustable, 1mL/h increment)
Power Supply : AC 110-230 V~ 50-60 Hz
Built-in battery : DC12V rechargeable lithium iron phosphate battery can allow the pump to operate at the infusion rate of 25 mL/h (middle infusion rate specified in EN60601-2-24: 2015) for over 5.5h, after it is charged for 16 hours
Dimensions : 282 mm (L) × 170 mm (W) × 120 mm (H)
Weight : 2 kg (include I.V clamp, customizable)
Infusion Set Compatible with 9 different brands of disposable infusion sets (5 brands pre-calibrated by the factory). It is recommended that the users calibrate any brand not listed before using it for the first time
Pre-calibrate for 5 brands of infusion sets
1. B.Braun
2. Lifeline
3. Romsons
4. PolyMed
5. JMS
Graseby 1200 Infusion Pump by Smith Medicals
- Graseby™ 1200 - Large Volume Infusion Pump
Easy to use.
Option to use 9 different brands of infusions sets which includes 5 frequently used brands that have been pre-calibrated
Direct rate input or automatic calculation of delivery rate based on volume and time setting
Infusion set loading guidelines displayed on the top of the pump
Removable pump mechanism that is easy to clean
Light weight
Post occlusion bolus reduction
Ultrasonic air sensor detects and alerts the patient and clinician if air is present in the infusion set
Built-in features to prevent the free flow of drugs
Infusion accuracy of ±5%
Built-in rechargeable Lithium-Ion battery
The pump has a standard RS232 interface for bi- directional communication.
Infusion Rate : 1 mL/h to 1200 mL/h
Flow Accuracy : ±5% (accuracy of qualified infusion set after calibration)
Priming / Bolus Dosage Rate : 1000 mL/h
Infusion Volume : 1 mLto 9999 mL
Accumulative Volume : 0 mL to 9999 mL (0.1 mL increment)
History Records : Up to 1500 records
Occlusion Alarm Threshold
High : 107.1 kPa to 174.8 kPa
Middle : 54.1 kPa to 110.2 kPa
Low : 2 kPa to 45.1 kPa
Ultrasonic Bubble Detector Sensitivity : ≥25 μL
KVO Rate : 0 mL/h to 5 mL/h (adjustable, 1mL/h increment)
Power Supply : AC 110-230 V~ 50-60 Hz
Built-in battery : DC12V rechargeable lithium iron phosphate battery can allow the pump to operate at the infusion rate of 25 mL/h (middle infusion rate specified in EN60601-2-24: 2015) for over 5.5h, after it is charged for 16 hours
Dimensions : 282 mm (L) × 170 mm (W) × 120 mm (H)
Weight : 2 kg (include I.V clamp, customizable)
Infusion Set Compatible with 9 different brands of disposable infusion sets (5 brands pre-calibrated by the factory). It is recommended that the users calibrate any brand not listed before using it for the first time
Pre-calibrate for 5 brands of infusion sets
1. B.Braun
2. Lifeline
3. Romsons
4. PolyMed
5. JMS
Graseby 1200 Infusion Pump by Smith Medicals
- Graseby™ 1200 - Large Volume Infusion Pump
Easy to use.
Option to use 9 different brands of infusions sets which includes 5 frequently used brands that have been pre-calibrated
Direct rate input or automatic calculation of delivery rate based on volume and time setting
Infusion set loading guidelines displayed on the top of the pump
Removable pump mechanism that is easy to clean
Light weight
Post occlusion bolus reduction
Ultrasonic air sensor detects and alerts the patient and clinician if air is present in the infusion set
Built-in features to prevent the free flow of drugs
Infusion accuracy of ±5%
Built-in rechargeable Lithium-Ion battery
The pump has a standard RS232 interface for bi- directional communication.
